PRODUCT Specs

General Information

Fuel type: Diesel
Mast type (standard): 3 stage Telescopic boom
Capacity A: 8000 lb (3,628.74 kg)
Capacity B: 3000 lb (1,360.78 kg)
@ Forward reach B: 23 ft (701.04 cm)
Notes: Independently operated stabilizers. Q-Fit carriage

Performance Specifications

Drawbar pull (max.): 19,620 lb
Travel speed forward, no load: 17.4 mph (28.00 kph)
Travel speed reverse, no load: 17.4 mph (28.00 kph)
Climbing performance, with load (%): 50

Attachments

Attachment 1, type: Q-Fit Quick hitch 55in

Power Specifications

Engine, make: Perkins
Engine, model: T4.236
Rated power: 89 HP
@ rpm: 2,200
Transmission, type: Shuttle
Transmission, make: JCB
Transmission, model: Synchro shuttle
Front axle, make: JCB
Rear axle, make: JCB
Gears forward: 4
Gears reverse: 4

Dimensions and Weight

Max. lift height: 36 ft (1,097.28 cm)
Max. forward reach: 23 ft (701.04 cm)
Lowered height: 98 inch (2,489.20 mm)
Machine length: 16.75 ft (510.54 cm)
Machine width: 90 inch (2,286.00 mm)
Machine wheel base: 98 inch (2,489.20 mm)
Outside turning radius: 16 ft (487.68 cm)
Machine weight (no load): 19,750 lb (8,958.45 kg)
Gross weight (with load): 27,750 lb (12,587.19 kg)

Wheels, Tires and Brakes

Wheel number: 4
Wheels driven: 4
Tyres, type: Pneumatic
Tyre size, front: 15.5x25 12PR
Tyre size, rear: 15x19.5
Brakes, type (service): Disc
